Technical Data:
| Model | 920 | 1228 | 1636 | 2545 |
| Speed (pcs/min) | 300 | 250 | 160 | 120 |
| Max. Sheet size (mm) | 900x2000 | 1200 x 2800 | 1600 x 3600 | 2500x4500 |
| Max. Stacking Weight (kg) | 2000 | 2000 | 2000 | 2000 |
| Max.Stacking Pile Height (mm) | 1800 | 1800 | 1800 | 1800 |
| Lifting Type | Forks lifled by chain | Forks lifled by chain | Forks lifled by chain | Forks lifled by chain |
| Power of Forks Rotating | Hydraulic driving | Hydraulic driving | Hydraulic driving | Hydraulic driving |
| Lifting Power of Horizontal conveyor | Hydraulic driving | Hydraulic driving | Hydraulic driving | Hydraulic driving |
| Machine Size (mm) | 9500 x 3200 x 2400 | 9500 x 3200 x 2400 | 9500 x 4000 x 2400 | 11500 x 5500 x 2400 |
| Total Power (kw) | 12 | 13 | 13 | 15 |
| Machine Weight (kg) | 3000 | 3000 | 3200 | 3500 |
Description:
- Forward feed mode: after the hydraulic control of the paper stack in the middle and back is flipped for the second time, it is pushed by the lower dial cylinder. After the front loading cylinder receives the paper, it is directly brought into the storage section.
- Semi-automatic mode: manually turn the paper, put into the storage section. (for paper stacks stacked front and back).
- Dumping paperboards are transfered to stack-up convey part by belts, then it will be transfered to feeding table of printer in scale type.
- There are two auto flaps that can be motorized adjusting on both side of stack-up convey part.
- There is auto side quaring in front end of horizontal convey belts.
- The machine can fix the ground.
- Horizontal convey belts controlled automatically.
- Sliding rollers fixed on the ground, Automatic control board.
- Paperboards lifting by chain with photoelectric switch control.
- Touch screen computer control.
- The counter has a storage tank and can store goods.
