Description:
1. Fast speed, 40m/min.
2. No need skilled workers, person deployment is more flexible.
3. Reduce the labor intensity effectively.
4. With automatic tapping function, effetively solve the scissors fork.
5. Automatic coutting in the rear section, the finisehd products (1~99 pcs) can be stacked and sent to the conveyor according to the set number, which is conveinet for bundling.
6. With the fan assist air-drying function, it can speed up the carton adhesion, reduce defective prodcuts occurence.
Max. Length | 2800mm |
Min. Length | 340mm |
Max. Width | 1515mm |
Min. Width | 240mm |
Paper Feeder Height | 900mm |
Power | 5hp |
Machine Size | 4500mm x 1800mm |
Machine Weight | 2000kg |
Machine Speed | 40m/min |
