Functions & Features.
Basket stacker,accurate count, automatic pile/order change.
Servo control board convey, convey speed SYNC with board speed.
Suction convey board, carbon fiber rod automatic press board, board stack squareness, stable convey.
Suction order/pile change, servo control accurate order/pile change.
Servo controlled pallet platform stable lift/down, stacking fast & squareness.
Rear stopper servo controlled positioning, fast order change, accurate response.
Rear stopper automatic rise, move, get multiple orders in a pile, bundle stack.
Crawler-belt stacking platform, stacking quantity reach to settle, servo controlled pile expulsion
Standard with stairs, Pedal, Guard bar, easy operation and board inspection:
Standard 10” touch screen, easy on-site monitoring & operation.
Standard communication portal, control portal, link with dry-end CMS, automatic order change and management.
Standard with industry A/C, electrical components working under dustless、constant temperature & humidity environment.
Specifications
Effective width:1800mm~3300mm
Stacking speed:250m/min~400m/min
Stacking length: 3000mm~4500mm
Stacking height: 1800mm~2000mm
Optional Function:
