Desctription:
- Touch screen control, convenietn, safe, fast and accurate.
- No need skilled worker, new person can operate.
- Servo motor control, 3 seconds finished adjustment, more precision.
- Fully automatic adjsutment.
- Free of position baffle adjsutment.
- The cutting edge adopts arc cutting edge.
- Can shift the order without stop the main motor.
- 600 orders momory storage.
- Intelligent adjsutment, can minimize the harm to workers.
- Whole mechine adopt international famous electrical elements to ensure the quality (Schneider servo motor, device, PLC).
|
Item |
Specification |
|
Model |
2548 (optional Model 3048, 3548, 3068, 3590) |
|
Working Speed |
40 pcs/min |
|
Touch screen |
Touch screen operation, simple interface, easy to operate. |
|
Main drive frequency converter |
Fast drive |
|
Transmission mode of main motor |
Adopt belt drive, with good stability and low noise |
|
Angel cutting type |
Manual feeding |
|
Cutter servo motor |
Schneider 400W*4 |
|
Slotter depth servo motor |
Schneider 400W*1 |
|
Machine overall size |
（L*W*H）3500*1500*1550mm |
|
Main motor power |
1.5KW |
|
Main Power |
4KW |
|
Helical rack |
Design of helical gear makes the error smaller |
|
Min. slotting depth |
40mm |
|
Max.slottiting depth |
420mm |
|
Min.Slotting gap of kinives |
130mm |
|
Slotting precision |
±0.5mm |
|
Cutter size |
480mm |
|
Suitable sheet thickness |
2-12mm |
|
Bearing |
NSK, Harbin, C&U |
|
Machine weight |
1850KG |
